Free sports court and field blocks for AutoCAD (DWG): football, basketball, tennis, track, pools

About the dimensions

The courts use the playing dimensions that the international federations publish: for example 105 x 68 m for a football pitch, 28 x 15 m for a FIBA basketball court, 23.77 x 10.97 m for a tennis court and 13.4 x 6.1 m for a badminton court. Rules change and national and youth versions differ, so check the current rules of your federation before you build. Small-sided football, school and multi-sport courts, grounds that have no single fixed size and the lines of the larger fields are common sizes and simplified markings, not drawings of a rulebook.

The blocks are our own drawings of the common dimensions, simplified where a detail does not matter on a plan, and the library is not certified. It is meant to plan a facility, not to prove that a court is approved for competition. Take run-off areas, surfaces, lighting and safety distances from the rules of your federation and your local regulations.

Frequently asked questions

Which items are in the library?

Courts and fields for football, futsal, handball, basketball, netball, tennis, badminton, pickleball, padel, squash, table tennis, volleyball, beach volleyball, rugby, American football, field hockey, baseball and cricket, an athletics track with jump and throw areas, swimming pools, an ice rink, a boxing ring and judo and wrestling areas, equipment such as goals, benches and stands, and 3 layout markers. The page above lists every group with its count.

Can I use the blocks for a school or club with smaller courts?

Yes for the sizes that are included, such as the 90 x 45 m pitch, the 3x3 basketball court, the half courts, the 25 m pools and pickleball. For another size, explode the block and stretch the outline, or draw the lines from the court blocks as a guide.

Can I use the symbols in commercial projects?

Yes. They are free to use and modify in your own projects, including commercial ones. They are provided as is, without warranty.

Does it show that a court meets competition rules?

Courts and fields for more than 40 sports, from football, basketball, tennis and rugby to kabaddi, korfball, Gaelic games, polo and floorball, athletics tracks with jump and throw areas, pools and water polo courts, an ice rink and a curling sheet, combat and gymnastics areas, archery and shooting ranges, cue sports and table games, dressage arenas, equipment such as goals, benches and stands, and 3 layout markers. The page above lists every group with its count.

Can I change a symbol or add attributes?

Yes. Open the DWG, edit a block with BEDIT to change it or add attributes, and save. To update drawings that already contain the block, run ATTSYNC or replace the block. Make a backup first: attribute values can be lost if ATTSYNC is used carelessly.

Where do I find a ready-made set of these symbols for AutoCAD?

AutoCAD itself ships only a small set of sample blocks, so a full symbol set has to come from a library. Download the ZIP on this page and open the DWG: every symbol is a block. Insert one with INSERT (Blocks palette, Libraries tab, then pick the DWG) or drag it from DesignCenter (ADCENTER). You can also download a single symbol on its own.
